Construction Drawing Services: Transforming Engineering Analysis into Flawless Execution
As a telecom engineer or project manager, you know that the transition from a structural analysis to a buildable set of plans is the most critical juncture. Our Construction Drawing (CD) services ensure your design intent is perfectly translated into a compliant, error-free document for the field. We don’t just draft; we guarantee build accuracy and expedited jurisdictional approval.
Why Choose TDS for Construction Drawings? (The Engineer's Advantage)
Our expertise, honed through over 20000 completed projects in the A&E field, is structured to deliver immediate value to your project workflow:
Precision for Build Accuracy
Accelerated Approval & Compliance
Scale and Scope Versatility
The TDS Construction Drawing Deliverables
We generate a full suite of layouts and documentation using valuable client-provided data to cover every aspect of the project. These are the essential plans we provide:
- Detailed Site Plan
- Tower Elevations
- Mount/equipment details
- General Information Layout
- Electrical/Grounding Plan
FAQ for Telecom Professionals
What exact inputs does TDS need to start a Construction Drawing (CD) project?
To ensure we deliver an accurate and timely A&E package, we require a comprehensive set of engineering data and project documentation:
Carrier RFDS (Radio Frequency Design and Specifications) document
Structural analysis
Mount analysis
Site surveys
Site visit notes and photos
Previous construction drawings
What specific types of layouts are included in a typical CD package?
Our Construction Drawings are comprehensive and can include:
General Information Layout
Overall Site Plan
Detailed Site Plan
Tower Elevations
Existing and Final Equipment Layouts (both on tower and on the ground)
Site Survey Plan with Grading Details
Electrical/Grounding Plan
Plumbing Diagram
Can TDS produce other necessary documents like Lease Exhibits or Zoning Drawings?
Yes. Using the data we integrate, we are fully equipped to produce a range of reports, including Lease Exhibits and Zoning Drawings, alongside the final Construction Drawings.
Does TDS handle documentation for both new builds and site upgrades?
Our services cater to different project types, whether it’s a new build or an upgrade. We also cover a wide range of sites, from small cells to macro sites
What is the process for ensuring quality and accuracy in the final CD package?
We prioritize thorough reviews and accuracy in every project we undertake. We aim to minimize the need for revisions by implementing proper preparation protocols and extensive communication to understand your goals and objectives. Our goal is to deliver a final product that surpasses your objectives while adhering to strict timelines.
